Classification of coated aluminum coil

According to the thickness of the coating, coated aluminum coil can be divided into single-painted aluminum coil (4-20 microns);

double-aluminum coil coating (25 to 28 micron) and triply-coated aluminum coil (35-38 micron);

In accordance with surface coating of paint, aluminum coil stock colors can be divided into polyester (PE) painted aluminium coil,

fluorocarbon (PVDF) coating aluminium coil and Epoxy aluminum coil coating.

Our product is coated with high-performance fluorocarbon, polyester, polyurethane and epoxy coating, and is widely used for roofs, facade cladding, ceilings, aluminum curtains, composite panels, pipe wrap, advertisement plates, instrument panels, and other uses.

In addition to various color coated aluminum coil, we can also provide aluminum composite panel, aluminum ceiling, and sandstone tile, etc.

Color coated aluminum coil is achieved by coating and coloring treatment. Painted Aluminum coil is coated with high quality fluororesin paint which offers good weather resistance.

Generally speaking, painted aluminum coil for sale now in HAOMEI Aluminum mainly includes PE aluminum coil coating and PVDF aluminum coil coating. The aluminum coil coating is ideal for producing aluminium composite materials. In addition, it is also widely used to manufacture aluminum ceiling, roofing, aluminum veneer and signboards.

1. Grade of aluminum coil colors

1 series: 1060 1100 etc.

3 series: 3003 3004 3005 etc.

5 series: 5052 etc.

8 series: 8011 etc.

2. Thickness: Roll Coating 0.05—3.0mm, Plate Coating up to 10mm

3. Width: 20-1600mm

4. Temper: H1X, H2X, H3X, H4X

5. Coating thickness (not including aluminum base): From 6 micron to 38 micron

6. Color: Metallic, Solid, RAL or by customer requirements.

7. Coating paint: PVDF, PE

8. Protective film: PVC film, Colorless transparent or White-black
